Kubernetes Helm Charts: A Complete Tutorial

Managing Kubernetes deployments efficiently can be challenging, especially as environments grow larger and more complex. Helm, Kubernetes’ package manager, simplifies lifecycle management by representing configurations as reusable templates called charts. Helm makes it easy to deploy, upgrade, and manage applications in Kubernetes clusters.

This complete tutorial covers foundational Helm concepts, steps to install and upgrade charts, how to create custom Helm charts, and managing chart dependencies.

Table of Contents

1. What is Helm? Concepts and Basics
   • Charts
   • Values
   • Templates
2. Installing and Upgrading Helm Charts
3. Creating a Custom Helm Chart
4. Using Dependencies in Helm
5. Final Thoughts

What is Helm? Concepts and Basics

Helm is a tool that streamlines Kubernetes deployment configurations into reusable packages called charts. Charts are collections of YAML files and templates that define Kubernetes resources.

Charts

A Helm chart is a package containing Kubernetes resource configurations. It consists of these components:

• Charts: Templates for Kubernetes objects like Deployments, Services, and ConfigMaps.
• Values: Override default configurations with custom inputs.
• Dependencies: Reusable charts nested as subcharts.

Directory Structure of a Helm Chart:

my-chart/
  Chart.yaml          # Metadata about the chart
  values.yaml         # Default configuration values
  templates/          # Kubernetes manifests in template format
    deployment.yaml   # Sample Deployment resource
    service.yaml      # Sample Service resource

Values

Values are dynamic inputs to Helm templates. They allow users to customize a chart. For example:

• A chart might define replicas in the values.yaml file: replicas: 3

Users can override this with a custom values.yaml during Helm installation:

helm install my-app ./my-chart -f custom-values.yaml

Templates

Templates use Go templating to dynamically render Kubernetes manifests. For example:

spec:
  replicas: {{ .Values.replicas }}

When a user provides replicas = 3 in the values.yaml, Helm renders:

spec:
  replicas: 3

Key Takeaways:

• Chart = Static package.
• Values.yaml = Dynamic inputs.
• Template = Customizable resource file generated at runtime.

Installing and Upgrading Helm Charts

Helm simplifies the process of deploying charts by using the helm install and helm upgrade commands.

Installing a Helm Chart

Step 1: Add a Helm Repository
Helm repos host charts for deployment. For example, add the official Bitnami repo:

helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo update

Step 2: Install a Chart
Use helm install to deploy a chart in a Kubernetes cluster:

helm install my-mysql bitnami/mysql

Command Breakdown:

• my-mysql is the release name.
• bitnami/mysql points to the MySQL chart in the Bitnami repo.

Check running resources:

kubectl get all

Upgrading a Helm Chart

Helm uses helm upgrade to modify or redeploy an existing release.

Update with an override:

helm upgrade my-mysql bitnami/mysql --set auth.rootPassword=MySecurePass

View the status of the deployed release:

helm status my-mysql

Diagram of Installation and Upgrade:

The chart templates are rendered dynamically and sent to the Kubernetes API server for deployment.

Creating a Custom Helm Chart

Creating custom Helm charts allows you to package your application’s resources for easy deployment.

Step 1 – Create a Chart Skeleton

Use helm create to scaffold a new chart:

helm create my-app

Generated Directory Structure:

my-app/
  Chart.yaml         # Metadata (name, version, description)
  values.yaml        # Configurable parameters
  templates/         # Kubernetes templates
    deployment.yaml  # Default Deployment manifest
    service.yaml     # Default Service manifest

Step 2 – Edit Templates

Customize Kubernetes templates, for example, deployment.yaml in templates/:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: {{ .Release.Name }}-app
spec:
  replicas: {{ .Values.replicas }}
  selector:
    matchLabels:
      app: {{ .Release.Name }}
  template:
    metadata:
      labels:
        app: {{ .Release.Name }}
    spec:
      containers:
      - name: app
        image: nginx
        ports:
        - containerPort: 80

Step 3 – Define Default Values

Update values.yaml to specify default settings:

replicas: 2

Step 4 – Install and Test

Deploy the chart:

helm install my-app ./my-app

Test the deployment:

kubectl get pods

Optional – Packaging and Sharing the Chart

Helm can package a chart into a .tgz file:

helm package my-app

The packaged chart can be distributed or uploaded to a Helm repository.

Using Dependencies in Helm

Helm supports dependencies between charts, allowing one chart to include reusable subcharts.

Step 1 – Add a Dependency

Edit the main chart’s Chart.yaml to reference dependent charts:

dependencies:
- name: redis
  version: 16.0.0
  repository: https://charts.bitnami.com/bitnami

Step 2 – Update Dependencies

Download the listed dependencies with:

helm dependency update ./my-app

Helm downloads the Redis chart and places it in the charts/ directory.

Step 3 – Use Dependency Values

Override dependencies in values.yaml:

redis:
  auth:
    password: myredissecret

Deploy with dependencies:

helm install my-app ./my-app

Visual Reference of Dependence Flow:

The parent chart (my-app) uses the Redis subchart to deploy both resources seamlessly.

Final Thoughts

Helm charts simplify Kubernetes deployments by transforming configurations into reusable packages. With the ability to customize templates, manage dependencies, and handle upgrades effortlessly, Helm is essential for any Kubernetes developer or operator.

Use this guide as your go-to resource for getting started with Helm, mastering advanced concepts, and navigating real-world deployments. Start managing Kubernetes workloads with confidence today!
